| Pressed Bearings |
 |
| |
| Bearing No. |
Dimension (mm) |
Ball |
| D |
d |
B |
L |
No. |
Dia |
| QCB2208 |
22 |
8 |
|
25 |
|
|
| QCB2812 |
28 |
12 |
|
35 |
|
|
| QCB3015 |
28 |
15 |
28 |
30 |
24 |
|
| Bearing No. |
Dimension (mm) |
Ball |
| D |
d |
A |
B |
E |
F |
C |
H |
No. |
Dia |
| QCC2608 |
26.1 |
8 |
|
13 |
17.5 |
31.3 |
8.5 |
4.5 |
15 |
5/32 |
| QCC2610 |
26.1 |
10 |
|
13 |
17.5 |
31.3 |
8.5 |
4.5 |
15 |
5/32 |
| QCC2612A |
26.1 |
12 |
|
13 |
17.5 |
31.3 |
8.5 |
4.5 |
15 |
5/32 |
| QCC2612B |
26.1 |
12 |
|
12.3 |
17.5 |
31.3 |
8.5 |
3.8 |
15 |
5/32 |
| QCC2712 |
27.1 |
12.1 |
16.7 |
12.3 |
18 |
30.2 |
8.5 |
3.8 |
12 |
3/16 |
| Bearing No. |
Dimension (mm) |
| D |
d |
b |
C |
E |
R |
| QCD2712 |
27 |
12 |
7.9 |
9.1 |
19.1 |
2.4 |
| QCD3215 |
32 |
15 |
7.9 |
9.1 |
23 |
3.6 |
| QCD3515 |
35 |
15 |
10.7 |
12.3 |
26.2 |
4.8 |
| QCD4020 |
40 |
20 |
11.9 |
12.7 |
31.8 |
3.6 |
| Bearing No. |
Dimension (mm) |
Bearing No. |
Dimension (mm) |
| D |
d |
B |
D |
d |
b |
| TVB2206 |
22 |
6 |
11 |
TVB2206 |
35 |
15 |
16 |
| TVB2408 |
24 |
8 |
13 |
TVB2408 |
38 |
12 |
19 |
| TVB2710 |
27 |
10 |
14 |
TVB2710 |
41 |
20 |
16 |
| TVB2912 |
29 |
12 |
14 |
TVB2912 |
44 |
20 |
24 |
| TVB3310 |
33 |
10 |
13 |
TVB3310 |
48 |
20 |
22 |
